Concept 3 Part Acoustic Partition Screen 1.8m High
Create more productive spaces with 3-part Acoustic Office Screen from the Concept range. At 1.8m high, the free standing design offers a dividing solution on a full height scale as well as flexibility for the space and noise control. Acoustic panels are suitable for offices, schools and open plan areas that require support and division.
To form the 3 part screens, each panels has 3 sections, all of which feature acoustic foam and a fabric colour of choice. Select up to 3 fabric colours to form a bespoke panel that’s made for you and your space. The 3 fabrics enhance the visual appeal but helps the finished result align with brand colours and current interior designs.
An added advantage is the powder coated aluminum frame that brings the design into a modern era. Black, white and silver frame options encase the solid core and acoustic foam, whilst including a built in linking function. Each panel includes a 2-way linking strip to combine numerous panels, forming a width and barrier of choice.
Dispatched in 10 Working Days
- Includes a set of Stabilising Feet & 2 Way Link Strip
- Finished in Silver, Black or White Aluminium, powder coated framework
- Manufactured with an 18mm solid core
- Quick and easy assembly
- Made to order to minimise waste
- Available in 5 widths, all at 1.8m high / 5.9ft
- Concept Office Screens have 12mm acoustic foam both sides
- Available in a choice of 25 fabric colours. Fabric sample available on request.
- Includes 3 Acoustic Panels within the office partition
Find out more about the Concept Office Partitions range.
- SKU
- 9143.1800
- Size
- 1800mm High
- Lead Time
- 10 Working Days
Description
The pairing of acoustic foam and fabric work together to remove excess noise from the environment, and gaining improved focus and concentration.
Key Features
- Full height panels
- Linkable to form other width options
- Made in the UK
- Wide range of fabrics
- Free standing design
Reviews
Customer Reviews
Production Specification
Product specifications for the Concept Acoustic Office Screen range.
Frame Measurements
Frame thickness - 28mm
Frame width - (side bars) - 50mm / (Top & bottom bar) - 22mm
Acoustic screen thickness (Core, foam & fabric) - 42mm
Foot slots in the frame are 290.5mm in from each end (Varied on screens 800mm W & smaller)
Materials
Frame - Powder coated aluminium
Stability feet - Steel
*stability feet are trip and wheelchair friendly
Feet raise the screen by 25mm and protrude 230mm from either side of the screen
Castor wheels (upgrade) Raise screen by 77mm & protrude 255mm each side of screen
Internal - 18mm solid core
Foam - 12mm fire retardant acoustic foam
Linking strips - Flexible PVC
Fire Safety Elements
Foam
12mm Combustion Modified Foam BS 5852-2: using ignition Source 5 Crib
Chipboard
Surface spread of Flames Class 2 tested to BS479-7
MDF
Surface spread of Flames Class 2 tested to BS479-7
Plastic Components
Manufactured using non-flammable, self-extinguishing plastic.
Aluminium
Extrusions has a melting of 660°C and is not considered to be a fire hazard.
Steel
Components are not considered to be a fire hazard.
Fabric Options
Woven Fabric
Woven Collection has been tested to BS 5867-2: 2008 & BS 7176 2007
Universe Fabric
Universe Collection has been tested to BS 5867-2: 2008 Type B
